Take on the biggest blizzards and snow piles.

Introducing our new patent-pending 6-bladed fan that moves over 50 tons/hour more snow!  Our serrated auger grinds through the snow, helping remove air pockets, making it more dense before it reaches the fan.  Our patent-pending 6-bladed ringed fan is consistently fed for maximum performance in even the heaviest, wettest snow conditions to virtually eliminate chute clogging.

Our new auger and fan system works in unison to create the best skid steer blower in the industry.

Serrated Helical Blade Auger for Tough Snow and Ice

Features a serrated helical blade auger that efficiently chews through compacted snow and ice, ensuring smooth operation in challenging winter conditions.

Durable 5/16-Inch Thick Flighting

With 5/16-inch thick flighting that’s 25% larger than competitors, the auger offers enhanced durability and longevity for heavy use.

Patent-Pending Snow Retainer Ring

The patent-pending snow retainer ring feeds a constant flow of snow directly to each fan blade, enhancing efficiency and preventing clogging.

Custom-Matched Hydraulic Motors

We custom-match hydraulic motors to your specific skid steer, ensuring optimal performance tailored to your machine’s specifications.

Enclosed Direct Drive Auger Motor

The direct-drive auger motor is fully enclosed for protection from snow, ice, and debris, ensuring reliable performance and reduced maintenance.

Seamless Spin-Formed Fan Wrapper

Spin-formed fan wrapper is perfectly round without weld seams, maintaining tight tolerances for cleaner snow streams and better performance.

Harmonically Balanced 6-Blade Fan

The precision 6-blade fan is harmonically balanced for smooth, vibration-free operation, reducing stress and extending equipment lifespan.

Large 11-Inch Chute Diameter

Extra-wide 11-inch chute prevents plugging and ensures even snow throwing for maximum productivity.

Hydraulic Control Valve with Electric Solenoid

A hydraulic control valve with an electric solenoid allows precise control of chute functions for enhanced convenience and efficiency.

Standard No-Freeze Chute

No-freeze chute resists icing, keeping the snow blower operational even in extremely cold conditions.

Cut-Back Serrated Sides

Serrated cut-back sides help the auger lead into hard-packed snow and ice, improving cutting efficiency in dense material.

Hydraulic Relief System

The hydraulic relief system protects components from damage due to hard impacts, eliminating the need for shear pins.

Robust Closed Rear Frame

The closed rear frame is extremely strong and resistant to bending, enhancing structural integrity during heavy-duty operation.

Heavy-Duty Reversible Cutting Edge

5/8-inch x 6-inch reversible cutting edge extends service life by allowing both sides to be used before replacement.

Easily Adjustable Skid Shoes

Skid shoes are easy to adjust for height, allowing you to set the desired ground clearance for optimal performance on varying terrain.

Contact

Specifications

Standard Flow or High Flow

Standard Flow:

Sizes available- 49”, 55”, 61”, 73”, 79”, 85”

Fan Blades- 6

Fan Diameter- 20”

Hydraulic Flow Requirements (gpm)- 49”-61” (11-22) 73”-85” (11-27)

Intake Height- 30”

Tons per Hour- 180

High Flow:

Sizes available- 61”, 73”. 79”, 85”, HP 73”, HP 79”, HP 85”, HP 97”

Fan Blades- 6

Fan Diameter- 24”

Hydraulic Flow Requirements (gpm)- 61”-85” (26-38) HP 73”-HP 97” (32-42)

Intake Height- 36”

Tons per Hour- 240
